Moving My Pi to an SSD

TL;DR

After setting a project aside for 5 years, I got my RPi4 booting from an SSD and running a 64bit OS by tweaking the USB_MSD_STARTUP_DELAY bootloader config parameter.

I run Home Assistant on a Raspberry Pi 4, using Docker Compose on Raspbian. This has worked great for me for years, and overall been very stable, but there’s been a Sword of Damocles hanging over the project: it was all running off the SD card. Eventually the SD Card would accumulate too many writes and fail. I had all the logging set up to use log2ram to minimize wear-and-tear, but this was a band-aid.

In 2020 the RPi got a firmware update that allowed booting from USB instead of the SD card, which allows using an SSD with an external enclosure. In 2021 I gave a shot to moving to SSD; there were a number of guides available on how to do this, so I bought:

And I gave a shot to copying the current SD card onto the SSD and booting up the Pi.

It didn’t work

I tried this a number of times and different ways. The SD card copied fine and if I hot-plugged the drive into the running Pi, I was able to mount it and browse the files. I triple checked the boot order, but if I left the SD card in the Pi it would boot off the SD card, and if I removed the SD card and let it try to boot…nothing.

At the time, I decided everything was working good ’nuf and I’d just restore from backup if the SD card crapped out. I put the drive and enclosure up on the Shelf of Despair with other half-finished projects.

Whoops, I need 64 bits

So, as with many homelab projects that Just Work…I let it keep on just working and left it alone. In 2025, though, Home Assistant announced that it was dropping support for 32-bit OSes, which meant if I wanted to continue getting updates for Home Assistant I’d need to reinstall my OS. This seemed like a good time to go ahead and move to an SSD.

I started by using RPi Imager to install Raspbian 64-bit to the same SSD with the same enclosure I was using before. I tried to boot off this perfectly clean install…and it still didn’t work. Same problems as before. After digging around online some more, I found that there’s a relatively common problem: the SSD enclosure doesn’t power up and come online as quickly as the bootloader is expecting, and the RPi gives up looking for a USB drive. There’s a setting that can fix this

USB_MSD_STARTUP_DELAY

If defined, delays USB enumeration for the given timeout after the USB host controller has initialised. If a USB hard disk drive takes a long time to initialise and triggers USB timeouts then this delay can be used to give the driver additional time to initialise. It may also be necessary to increase the overall USB timeout (USB_MSD_DISCOVER_TIMEOUT).

To see the current settings, you can run rpi-eeprom-config. I ran sudo rpi-eeprom-config --edit to update the setting according to whatever forum post I finally landed on (followed by a reboot to install the updated firmware config) and it now looks like this:

[all]
BOOT_UART=0
WAKE_ON_GPIO=1
POWER_OFF_ON_HALT=0

[all]
BOOT_ORDER=0xf41
USB_MSD_STARTUP_DELAY=20000
USB_MSD_BOOT_MAX_RETRIES=5

The BOOT_ORDER is specified here, and the default 0xf41 means “Try SD first, followed by USB-MSD then repeat (default if BOOT_ORDER is empty)”. The USB_MSD_STARTUP_DELAY is the value I upped to 20s, and it, along with the max_retries, seems to have solved the problem for me. I didn’t experiment further to see if a lower value would work, but it’s definitely somewhere between 5s and 20s for my combination of hardware.

I copied over the docker directory (which contained the MariaDB files and all my configs) from my backup to the new drive, as well as a few other services, and now everything’s running happily again.
